Motor stops running in flight.
Motor restarts abnormally ESC
Overheats
12. G / L
UARANTEE IABILITY
Our products are covered by the currently valid statutory guarantee regulations. If you wish to make a claim under guarantee, please
contact the model shop where you originally purchased the unit.
The guarantee does not cover faults caused by:
Incorrect handling, incorrect connections, reversed polarity
•
The use of accessories other than original MULTIPLEX items
•
• Modifications or repairs not carried out by MULTIPLEX or by an authorised MULTIPLEX Service Centre
• Accidental or deliberate damage
• Normal wear and tear
• Use of the unit outside the stated Specification
MULTIPLEX Modellsport GmbH & Co.KG accepts no liability for loss, damage or costs which are caused by the incorrect or
incompetent use of the product, or are connected with such use in any way.
13. CE C D
ONFORMITY
This device has been assessed in accordance with the relevant harmonised European directives. You are therefore the
owner of a product whose design fulfils the protective aims of the European Community relating to the safe operation of
equipment. You are entitled to see the conformity declaration. Please ask MULTIPLEX Modellsport GmbH & Co.KG for a copy.
14. D N
ISPOSAL OTES
Electrical equipment marked with the cancelled waste bin symbol must not be discarded in the standard household waste;
instead it must be taken to a suitable specialist disposal or recycling system. In the countries of the EU (European Union),
electrical equipment must not be discarded via the normal domestic refuse system (WEEE - Waste of Electrical and
Electronic Equipment, Directive 2002/96/EG). You can take un-wanted equipment to your nearest local authority waste
collection point or recycling centre, where the staff will dispose of it correctly and at no cost to yourself.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating instructions
MULTIcont BL-60 SD
Lost throttle signal
Battery Pack voltage has
reached the Low Voltage
Protection threshold.
Possible bad cable
connection
Possible RF Interference at
the flying field.
Inadequate Ventilation
Servos drawing too much
current and over loading the
ESC.
Over sized motor or prop
E
XCLUSION
ECLARATION
Check proper operation of the radio equipment.
Check the placement of the ESC and the Receiver
and check the route of the receiver's aerial and ESC
cables to ensure there is adequate separation to
prevent RF interference.
Install a ferrite ring on the ESC's throttle cable.
Land the model immediately and replace the battery
pack.
Check and verify the integrity of the cable connections
The normal operation of the ESC may be susceptible
to surrounding RF interference. Restart the ESC to
resume normal operation on the ground to verify
recurrence. If the problem persists, test the operation
of the ESC at a different flying field.
Relocate the ESC to allow better ventilation
Use servos that are adequately sized for the ESC.
The maximum BEC current drawn should be within
the BEC limits.
Reduce Prop size or resize the motor
