10. Low Voltage Cutoff Type : Reduce Power / Hard cutoff
* Reduce Power – ESC reduces motor power when the pre-set Low Voltage Protection Threshold value is reached. (recommended)
* Hard Cutoff – ESC instantly cuts motor power when the pre-set Low Voltage Protection Threshold value is reached.
6. P M
ROGRAMMING ODE
Programming Mode Audible Tones
0 Throttle Calibration
(within the first 4 Sec )●● ●● ●● ●●
1 Brake
_ * _ * _ *
2 Battery type
～ ～ ～ ～
～～ ～～
3 Low Voltage Cutoff Threshold
*_ _* *_ _* *_ _* *_ _*
*_ _ _* *_ _ _* *_ _ _* *_ _ _*
*_ _ _ _* *_ _ _ _* *_ _ _ _* *_ _ _ _*
4 Restore Factory Setup Defaults
— — — —
5 Timing Setup
– – – –
–– –– –– ––
––– ––– ––– –––
6 Soft Acceleration Start Ups
∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨
∨ ∨ ∨ ∨
∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨ ∨
7 Governor Mode
_*_ _*_ _*_ _*_
_**_ _**_ _**_ _**_
_***_ _***_ _***_ _***_
8 Motor Rotation
W W W W
9 Switching Frequency
// // // //
\\ \\ \\ \\
10 Low Voltage Cutoff Type
＿ˉ＿ˉ＿ˉ＿ˉ
ˉ＿ ˉ＿ ˉ＿ ˉ＿
Using Your New ESC
Improper polarity or short circuit will damage the ESC therefore it is your responsibility to double check all plugs for proper polarity
and first fit BEFORE connecting the battery pack.
Alert Tones
The ESC is equipped with audible alert tones to indicate abnormal conditions at power up.
1. Continuous beeping tone (****) – Indicates that throttle stick is not in the minimum position.
2. Single beeping tone followed by a one second pause (* * * *)– Indicates that the battery pack voltage exceeds the acceptable
range. (The ESC automatically checks and verifies the battery voltage once the battery is connected).
Built-in Intelligent ESC Safety Functions
1. Over-heat protection: When the temperature of ESC exceeds 110 deg C, the ESC will reduce the output power to allow it too
cool.
2. Lost Throttle signal protection: The ESC will automatically cut power to the motor when it detects a lost of throttle signal for 2
seconds, then the motor will emit continuous beeping tone.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating instructions
MULTIcont BL-60 SD
A T
UDIBLE ONES
_ *
～～ ～～
ESC Functions
Brake On / Off
NiCd
LiPo
Low 2.8V/50%
Medium 3.0V/60%
High 3.2V/65%
Restore
Automatic (7-30°)
Low (7-22°)
High (22-30°)
Very Soft
Soft Acceleration
Start Acceleration
RPM off
Heli first range
Heli second range
Forward / Reverse
8 kHz
16 kHz
Reduce Power
Hard Cut Off
