Original operating instruction - GOJAK 7016
Individual parts
16
17
20
9
Nr. Article number
411300
1
411301
2
3
411302
411304
4
411305
5
411306
6
411307
7
8
411308
411326
9
10
411313
411314
11
Specifications
Material: Steel
Weight [kg]: 24,0
Dimensions W x H x L [mm]: 525 x 190 x 655
GoJak wheel ø [mm]: 76
Permissible tyre width [mm]: up to 406
Technically permissible load capacity [kg]: 782
Technically permissible speed [km/h]: 10
6
17
2
15
21
Name
Locking claw
Lower pivot pin
Pedal spring RIGHT
Disc
Split pin
Spring for switch lever
Screw with washer
Switch lever
Wheel 4'' incl. Bearings/Screws/Nuts 20
Working claw
Spring for working claw
7
8
1
13
14
4
3
4
5
Nr. Article number
12
411315
13
411316
14
411317
15
411328
16
411329
17
411330
18
411321
19
411333
183621
21
409955MU
English
19
11
10
12
18
Name
Upper pivot pin
Bracket for stop disc
Stop disc
Steel roller drum
Roller bearing
Screw
Pedal lock right
Pedal
Screw
Wheel fastening nut
7
