6 English
5. OPERATION IPC-2 / IPC-3
5.1 Checking before Operation
1. Check the input power and surroundings is comply with the conditions of using. IPC-2 / IPC-3 are
not intended for 380-400V in the current version.
2. Check whether the pressure sensor is connected with the system .
3. Check that the device is installed firmly and vertically in the direction of flow.
4. The pump starts (it is essential to refer to the operating instructions for the pump to find out
what conditions must be met before starting up the pump) after connection is verified. If the
pump is three phase, please check whether the direction of motor revolve is correct. If the motor
rotates inversely, please exchange the terminal of UV, WV or WU, also it can be reversed adjust
through the slide switch.
5.2.1 Operating Steps
1. Connect power ,pressure display "00.00"bar, the power indicator lights.
2. Open the outlet valve,press "RUN" and start the pump
3. Any conditions can press "STOP", and stop the pump
" or " " can check the working pressure, if want to change the pressure press "
4. Press "
increase the setting pressure or press "
5. Open the tap after setting pressure, the inverter will take frequency speed control on pump
according to the water using status .Observing whether the pump is running normally, the
pressure showed in the display whether is constant. If it does, the installation and debugging is
finished, content to remove the faults and debug it again .
5.2.2 Button and Function Instruction
Schematic Diagram
" to reduce the setting pressure
IPC-2
No. Name or Function
Press the button one time can reduce 0.1bar,
1 Reduce button
long time press can reduced rapidly
Press the button one time can increase 0.1bar,
2 Increase button
long time press can increase rapidly
RUN/STOP It can start the pump manually, press this button
3
button to exit the water shortage state
Current pressure Display value indicates the current pipe network
4
display pressure value,unit:bar
5 Power indicator Indicator lights up when power is connected.
When the main pump speed operating state
or when motor is in speed governing state,the
indicator flash quickly. When the main pump at
6 Pump indicator the constant speed work state or water shor-
tage, the indicator flash slowly. When it stop
automatically,the indicator is on. When it stop
manually ,the indicator is off.
The light is flashing when working in the setting
Pressure setting
7
indicator pressure value
The indicator flash , it means the pipe is
Water shortage watershort. It will restart in setting time and the
8
indicator interval time for restart is 8S, 1min , 10min ,
30min , 1h , 2h ....restart
Display value indicates the current setting
Set pressure
9 pressure value,unit:bar. Factory default Settings
display area
is 3bar
" to
Instruction
