Operating instructions
The unit is designed for a temperature range between 5 and 35°C. Below 5°C the humidity
tends to be very low, so you do not need to use a dehumidifier. Above 35°C, the overheating
protection may automatically switch off the unit. The unit is not approved for operation outside
the temperature range.
In order for the dehumidifier to dehumidify optimally, it warms the air. Therefore, the room
temperature may rise by 1-2 degrees. This is quite normal and increases the efficiency of the
unit.
When the water tank is full, the machine switches off automatically.
To protect the compressor, it has a switching delay of 3 minutes. Wait 3 minutes until the
dehumidifier resumes dehumidification.
Technical data
Product name:
Voltage:
Rated power:
(30°C 80% humidity)
Current consumption:
(30°C 80% humidity)
Max. suction/pressure side
Operating pressure:
Dehumidification capacity:
Weight:
Permissible operating temperature:
Refrigerant / Amount:
Water tank size:
Noise emission:
Dimensions:
Air flow rate fan stage 1:
Air flow rate fan stage 2:
Device description
Figure 1:
Control panel
Humidity display
3-coloured
Front panel
EN-7
Castor
Comedes Demecto 12
AC220-240V/50 Hz
200W
1,2 A
0.7MPa / 3.2MPa
12 l/ day (30°C 80% humidity)
10.0 kg
5-35°C
R290/50g
2,0 l
≤ 38 dB(A)
255x220x445 mm
100m³/h
120m³/h
Side part
