1. PRODUCT DESCRIPTION
FAN UNIT(S)[1]
OPTION: VALVE SET + THERMO-
STATIC HEAD
* CONNECTING THE CONTROL UNIT
[3]
[2]
[1]
JAGA N.V. | STRADA HYBRID - ACO/B | MANUEL | 2024.06.14 | V.2.05
POWER SUPPLY 230
VAC (IN) / 24 VDC
(OUT) [2]
WATER TEMPERATURE SENSOR
(TW) [4]
CONTROL PANEL WITH
CURLY CORD [3]
CONTROLLER*
ROOM TEMPERATURE SENSOR
(TK) [5]
[5]
[4]
