the machine on and off, keep it away from dust
deposits. After switching off the machine, only place
it down when the motor has come to a standstill.
Avoid inadvertent starts: always switch the
tool off when the plug is removed from the
mains socket or if there has been a power cut.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore, always hold the machine with
both hands using the handles provided, stand in a
safe position and concentrate.
Machines with the designation W...RT:
Torque activation (with dead man's lever)
I
Switching on: Slide the trigger switch (17)
forwards and then push the trigger switch
(17) upwards.
Switching off: Release the trigger switch (17).
Machines with the designation W...RT:
Continuous operation (depending on features)
I
Switching on: Switch the machine on as described
above. Now slide the trigger switch (17)
forwards again and release in the front
position to lock the trigger switch (17)
(continuous operation).
Switching off: Push the trigger switch (17)
upwards and release.
8.3 Working Directions
Surface routing and grinding:
Place the machine with the entire surface of the tool
onto the workpiece. Apply moderate pressure and
move it to and fro across the surface.
9. Maintenance
Replace worn or damaged routing wheels (see
figure, page 2):
- Removing the routing tool (see chapter 7.2).
- Extract the screw (13) in an anticlockwise
direction. Remove the safety disc (14).
- Replace all routing wheels as shown.
(Always use the same type of routing wheels).
-Reassemble all parts as shown.
Insert and turn the screw (13) in a clockwise
direction and tighten with 13 Nm ± 1 Nm.
17
0
17
0
10. Cleaning
Cleaning the motor: It is possible that particles
deposit inside the power tool during operation. This
impairs the cooling of the power tool.
The power tool should be cleaned regularly, often
and thoroughly through all front and rear air vents
using a vacuum cleaner or by blowing in dry air.
Prior to this operation, separate the power tool from
the power source and wear protective glasses and
a suitable dust mask. Ensure appropriate suction is
available when blowing out vents.
11. Troubleshooting
Machines with VTC and TC electronics:
The electronic signal display lights up
and the load speed decreases (not
W...RT). (15) There is too much load on the
machine! Run the machine in idling until the
electronics signal indicator switches off.
The machine does not start. The
electronic signal display (15) (depends
on model) flashes. The restart protection is
active. If the mains plug is inserted with the machine
switched on, or if the power supply is restored
following an interruption, the machine does not start
up. Switch the machine off and on again.

12. Accessories

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Always use the suitable tool and the supplied
guard for the application.
Task: Routing
- Tool: Routing head
Task: Surface grinding
- Tool: "Masonry/concrete" diamond cup wheel
Work only with appropriate dust extraction: connect
an all-purpose vacuum cleaner class M to the
extractor connection piece.
For a complete range of accessories, see
www.metabo.com or the catalogue.
13. Repairs
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
A defective mains cable must only be replaced with
a special, original mains cable from metabo, which
is available only from the Metabo service.
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
