en ENGLISH
6 Routing tool*
7 Spindle
8 Extractor connection piece
9 Spindle locking button
10 Clamping nut *
11 Diamond cup wheel*
12 Support flange *
13 Screw *
14 Safety disc*
15 Electronic signal indicator
16 Speed adjustment wheel
17 Trigger switch
18 Handle
19 Safety guard
20 Flat area for working close to edges
21 Wing nut
22 Depth stop
* depending on equipment/not in scope of delivery

6. Initial Operation

Before plugging in the device, check that the
rated mains voltage and mains frequency, as
specified on the rating label, match your power
supply.
Australia: Always use a residual current device
(RCD) protected supply with a rated residual
current of 30 mA or less.
6.1 Fitting of bar auxiliary handle
Always work with the bar auxiliary handle (1)
attached! Fit the bar auxiliary handle as shown
(see illustration A, page 2).
- Fit locking discs (3) to the left and right of the gear
housing.
- Fit the bar auxiliary handle (1) at the gear housing.
- Insert the thumb screws (2) left and right into the
bar auxiliary handle (1) and turn gently.
- Adjust the bar auxiliary handle (1) to the required
angle.
- Firmly tighten the thumb screws (2) to the left and
right manually.
6.2 Adjusting the depth stop
For safety reasons, only use the safety guard
(19) provided.
See figure, page 2.
- Release wing screw (21).
- Twist the depth stop (22) to adjust the height in
relation to the accessory and the work task.
- Hand-tighten the wing screw (21) securely.
6.3 Dust extraction
Always use a suitable dust extraction system:
Connect an M-class vacuum cleaner to the
extractor connection piece (8).
For optimal dust extraction, use the connecting
sleeve 6.30796.
We recommend using an antistatic suction hose
with diameter 35 mm.
14
7. Attaching the accessory
Disconnect the mains plug before changing
any accessories. The machine must be
switched off and the spindle must be at a standstill.
7.1 Locking the spindle
Press in the spindle locking knob (9) only
when the spindle is stationary!
- Press in the spindle locking button (9) and turn the
spindle (7) by hand until you feel the spindle
locking button engage.
7.2 Fitting/removing the routing tool
For safety reasons, use the safety guard (19)
with the attached depth stop (22).
See illustration B on page 2.
To fit:
- Lock the spindle (see chapter 7.1).
- Screw on and tighten the routing tool (6) using the
2-hole spanner (5) in a clockwise direction.
To remove:
- Lock the spindle (see chapter 7.1). Unscrew the
routing tool (6) with the 2-hole spanner (5) in an
anticlockwise direction.
7.3 Fitting/removing the diamond cup wheel
For safety reasons, use the safety guard (19)
with the attached depth stop (22).
See illustration C on page 2.
To fit:
- Fit the support flange (12) on the spindle. (7) The
flange should not turn on the spindle when
properly attached.
- Lay the diamond cup wheel (11) on the support
flange (12) so that it lies flat along the support
flange.
- The 2 sides of the clamping nut (10) are different.
Screw the clamping nut onto the spindle so that
the band of the clamping nut (10) is facing upward.
- Lock the spindle (see chapter 7.1). Turn the
clamping nut (10) clockwise using the 2-hole
spanner (5) to secure.
To remove:
- Lock the spindle (see chapter 7.1). Turn the
clamping nut (10) anticlockwise using the 2-hole
spanner (5) to unscrew.
8. Use
8.1 Setting speed
Set the optimum speed on the setting wheel (16),
depending on the application.
8.2 Switching On and Off
Always guide the machine with both hands.
Switch on first, then guide the accessory
towards the workpiece.
The machine must not be allowed to draw in
additional dust and shavings. When switching
