8 Pairing two receivers with one transmitter.
If more than 3 motors and one servo is required for a model, then 2 receivers can be addressed
with one transmitter without interference between them.
Proceed as follows to do this:
1.
There is already one receiver paired with a transmitter as described in Chapter 2.
2.
Another receiver is connected with a fischertechnik 9 V power supply (rechargeable battery
pack, power pack). The blue LED flashes 1x per sec.
3.
Press the "Select" button on the transmitter once briefly. The LED now flashes yellow. Then
press the "Select" button longer (approx. 3 sec.) until the yellow LED flashes rapidly. By
pressing the "Select" button longer (approx. 3 sec.) on the second receiver, this is also set
into pairing mode.
4.
The blue LED on this receiver changes to yellow and lights up continuously. The receiver is
connected with the transmitter as "Receiver 2".
5.
Now by briefly pressing the "Select" button you can switch between Receiver 1 and Receiver
2. The blue/yellow LED lights continuously on the relevant paired receiver. The LED on the
non-paired receiver flashes slowly (approx. 1x per sec.)
This pairing process also has to be performed only once. Afterwards the devices detect each other
automatically and connect as soon as they are switched on.
9 Several Control Sets in One Room
The Bluetooth remote technology enables operation of as many control sets as desired. These sets
consist of one transmitter and one or two receivers in the same room, without interfering with
each other. Only be careful if during the pairing process several transmitters and/or receivers are
in one room, switched on and pairing mode is activated. It can happen that the wrong receiver is
paired. Therefore only one receiver should be put into pairing mode at the same time.
