10 Min.: If the SPEED/FEED button is pressed for 5 seconds, the LED 10 min. lights up. The
pump is stopped for 10 minutes and then starts again. If you want to start it earlier,
press the SPEED/FEED button again for 5 seconds.
TIMER/LOCK: By briefly pressing, you can change channels (time display in timer, Fig. 2, No. 1)
or operate the unit without channels (- - display in the timer, Fig. 2, No. 1). If the
button is held down a bit longer, the red "Lock" LED will illuminate and the controller
(Fig. 2, No. 4) can no longer be adjusted despite turning it.
+/-: Set the switch interval of channel A to B. 1 - 60 minutes can be adjusted. Set the
pump mode and speed mode for both channels first without time (display - -), then
set the desired time interval.
Night Mode: After the light sensor has been connected to the EcoDrift Control 0 – 10 V (Fig. 1), the
night mode can be activated by pressing the MODE/NIGHT button on the Wireless Master Controller
a bit longer. The night mode is activated and displayed by a LED (Night). In night mode, at darkness
without changing channels, all pumps with light sensor automatically reduce the power to half power.
To use the night function, the light sensor has to be attached to a lighted place, but not directly at
a very bright light source as this may damage the sensor. The sensor is not encapsulated waterproof.
Please protect it from condensate and respect a maximum of 80% air humidity.
Fig. 2: EcoDrift Wireless Master Controller
1. Switch interval 1 - 60 minutes
2. Pump power 20% steps
3. Connection for 0 - 10 V control
7. Warranty
Should any defect in materials or workmanship be found within 24 months of the date of purchase
AB Aqua Medic undertakes to repair, or at our option replace, the defective part free of charge –
always provided the product has been installed correctly, is used for the purpose that was intended
by us, is used in accordance with the operating instructions and is returned to us carriage paid. Proof
of Purchase is required by presentation of the original invoice or receipt indicating the dealer's name,
the model number and date of purchase. This warranty may not apply if any model or production
number has been altered, deleted or removed, unauthorised persons or organisations have executed
repairs, modifications or alterations, or damage is caused by accident, misuse or neglect. Please note
that the product is not defective under the terms of this Warranty where the product, or any of its
component parts, was not originally designed and / or manufactured for the market in which it is
used. These statements do not affect your statutory rights as a customer.
AB Aqua Medic GmbH - Gewerbepark 24 - 49143 Bissendorf/Germany
6
4. Controller
5. Pump mode
6. Channel display
- Technical changes reserved - 06/2016
for pulse frequency
