TP-Link tapo RV20 Mop Plus V1 Bedienungsanleitung Seite 6

English
Auto-Empty Dock
LED Indicator
• White: Working properly
• Off: Robot vacuum is connected to the dock; sleeping.
• Solid Red: Dust bag not installed; top cover not closed.
• Flashing Red: Error
Top cover
Open to install/take out the dust bag.
Put the cover back on each time you open it.
Dust Bag Compartment
Charging Contacts
Dust Collection Port
The dust in the robot vacuum will be collected
into the dust bag through the port.
4
Fan Filter
Dust Bag Handle
Dust Bag
