FITTING INSTRUCTIONS FOR LP0261BK LICENCE PLATE BRACKET
(FOR USE WITH STANDARD AND R&G MINI INDICATORS (8mm))
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
Please note that the way the kit is packed does not necessarily represent the way of mounting to the
T
HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY
Digital copies of these instructions are available to download from
Please note that in cases where kits are packed with rubber washers holding the components onto the bolt
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
KAWASAKI NINJA 125/Z125 2019-
bike
GENERAL TORQUE SETTINGS
M4 BOLT = 8Nm
M5 BOLT = 12Nm
M6 BOLT = 15Nm
M8 BOLT = 20Nm
M10 BOLT = 40Nm
– the rubber washers should be thrown away!
TOOLS REQUIRED
• Set of metric Allen keys to include 4 and 5mm A/F .
• Socket set to include 10mm A/F socket and wrench.
• Small amount of super glue.
• Phillips driver.
• Heat gun or hair dryer.
R&G Racing
racing.com
(
FOR CLARITY OF INSTRUCTIONS ONLY
www.rg-racing.com
www.rg-racing.com
LP0261
)
Email: info@rg-
