damage material Preventing
Preventing material damage
▶ Never kink, crush, modify or cut through
damage material Preventing
water hoses.
▶ Only use the water hoses supplied with
the appliance or genuine spare hoses.
▶ Never re-use water hoses that have been
used before.
▶ Secure the connection points correctly
using hose clamps.
▶ Only remove the filter container for main-
tenance work and then reinsert it cor-
rectly.
▶ Never remove the filter container during
operation.
▶ Only use the scraper provided to remove
microplastics from the filter container.
▶ Never knock the filter container against
other objects to loosen microplastic
residues.
▶ Do not use harsh or abrasive detergents.
▶ Do not use cleaning products with a high
alcohol content.
▶ Do not use hard scouring pads or clean-
ing sponges.
▶ Clean the appliance using only water
and a soft, damp cloth.
▶ Remove all detergent residue, spray
residue or other residues immediately if
they come into contact with the appli-
ance.
connection and Installation
Installation and connection
connection and Installation
Unpacking the appliance
Remove any packaging and protective
1.
covers completely from the appliance.
Check the appliance for visible damage.
2.
Included with the appliance
After unpacking all parts, check for any
damage in transit and completeness of the
delivery.
¡ Appliance
¡ Accompanying documents
¡ Power supply (model:
YL361-2401500V)
¡ Water outlet hose
¡ Hose clamps and cable ties
Preventing material damage en
Appliance
You can find an overview of the parts of
your appliance here.
→ Fig.
1
Filter housing
1
Status light
2
Filter container
3
Filter cover
4
Scraper
5
Filter net
6
Rotary head
7
Mains connection
8
Water inflow
9
Water outlet
10
Disposing of packaging
The packaging materials are environment-
ally compatible and can be recycled.
Sort the individual components by type
▶
and dispose of them separately.
Requirements for the installation loc-
ation
Follow these instructions when installing
your appliance.
¡ The ground must be level and stable.
The appliance feet must adhere to the
surface.
¡ The clearance between the appliance
and the washing machine must not ex-
ceed 100 cm.
¡ The clearance between the appliance
and the floor must be between 12 cm
and 100 cm.
Note: Do not trap the power cord or the
hoses between the wall and the appliance.
Installation types
You can set up the appliance on the wash-
ing machine or on the worktop, within a
cupboard or beside the washing machine.
→ Fig.
2
9
