Technical Information
Battery
Adapter Input
Output
Motor Power
Battery Charge Time
Usage Time
Powder Chamber Capacity : 0.5 Liter
Filter
Lifespan
Handheld Usage Time
Preparing the Vacuum Cleaner
Remove all packaging materials, the vacuum cleaner and the accessories. Remove any
adhesive foils, adhesive labels and papers from the appliance.
Installation the Vacuum Cleaner
•
To assemble the vacuum cleaner, first attach the vacuum cleaner head (1) to the metal
vacuum pipe. and make sure that the lock is fully engaged, a click should be heard.
•
Insert the tube (3) into the compartment in the brush chamber and fully insert the lock.
•
Make sure it is seated, there should be a click.
•
Insert the motor head of the cleaner into the compartment at the end of the pipe.
insert it and make sure that the lock is fully seated, a click should be heard.
•
Place the battery (10) of the device in the chamber located in the head compartment and
snap it into place, there should be a click.
Charging the Battery
Turn off the the vacuum cleaner before charging!
•
Place the vacuum cleaner to the charging dock. You shall discharge the battery
completely at initial operation, and then recharge it completely.
•
Connect the dock to the mains using the adaptor. Charge level of the battery is displayed
with a light indicator.
•
Battery is completely recharged after approx. 3-5 hours.
•
This appliance is equipped with battery overcharging protection. Charging shall be
stopped when maximum charge level is reached.
: 29.6V 2500mAh 3.5A Li-ion Battery
: 100-240V/50-60Hz 0.5A 15W
: 35V 500mA
: 350 W BLDC Motor (Unite) 20 W DC Motor (Brush)
: 3-3.5 hours
: High:>=10 min., Medium:>=20 min., Low:>=40 min.
: H10 HEPA
: 10 years
: High:>=14 min., Medium:>=24 min., Low:>=46 min.
