Operation
ee
1. When the PRESS MATCHING KEYS and
LEARNED/SENDING indicator [1] are flashing, press
the use/learn switch [2]. When the indicators stop
flashing, the system is waiting for operation input. [f
Changing Commands
@ Commands should be memorized using the system
outlined in section, "Learning Remote Contro/ Codes."
New codes of newly-entered keys only are modified,
and the codes of previously memorized keys are not
the indicators are not flashing, it means the use mode modified.
has already been entered automatically. @ Tomemorize new codes after clearing all previous codes:
2. Next, press the keys for each function and operate the 1. Press the use/learn switch to enter the learn mode.
remote control transmitter. During remote control 2. While the PRESS MATCHING KEYS and
transmission, the LEARNED/SENDING indicator [1] LEARNED/SENDING indicators are flashing, press
lights. If a key that has not been memorized is pressed, the clear switch once. All previously- memorized
the ERROR indicator [1] (red) lights. codes are cleared. (To confirm whether the codes
3. There is no power switch on the remote control trans- were cleared, enter the use mode and press the keys
mitter. Power is supplied automatically when a key is for each function. If they have been cleared, the
pressed. If no key is pressed for a short interval, power ERROR indicator will light.)
goes off automatically, to avoid wasting the battery. 3. Memorize the new codes using the system explained
in "Learning Remote Control Codes."
NOTE:
Error Indicator
Fa rd a ee eee ee
Please check whether previously-memorized functions
are working properly. Cases particularly liable to mal-
function are those in which two keys are used simul-
taneously, for example when recording a video or audio
The ERROR indicator lights in the following cases.
source, or in which several kinds of information are e
transmitted at the same time, as when setting the timer .
to record a program.
Learn mode
If no command has been memorized, the ERROR indi-
cator [1] flashes 5 times.
@ Use mode
e fa key that has not been memorized is pressed, the
ERROR indicator [1] lights.
« lf two or more keys are pressed at the same time, the
ERROR indicator lights. However, the " -REC—" keys
are exceptions. These two keys must be used simul-
taneously for operation to occur.
@ All Indicators Lights
« When the memory is overloaded, all indicators flash 5
times. Further memorization is impossible.
« If the batteries run out, all indicators light. Replace the
batteries.
Troubleshooting guide
Nn Se
lf the remote control transmitter does not operate, @ First, try operations using the buttons of the main unit
for each function. If operation is not possible, the fault
is in the main unit and not the remote control trans-
mitter.
@ if the batteries are weak, replace the batteries.
The keys of this remote control transmitter cannot be
memorized or one part of the functions cannot be mem-
orized :
@ This remote contro! transmitter uses an infrared ray
system and therefore most functions can be memorized.
However, there may be some instances where mem-
orization is not possible or one part of a function cannot
be memorized.
It is difficult to memorize using the keys of this remote
control transmitter, and even when a function has been
memorized, operation is incorrect.
® This remote contro! transmitter is not aimed directly
at your existing remote control unit, or the distance
between the two units is out of range. Confirm that
these two factors are corrected.
@ Confirm whether the batteries of your existing remote
control transmitter are weak. (If the batteries are weak,
it may be impossible to operate a function or to mem-
orize functions. Insert new batteries and try again.)
