HANSGROHE ShowerSelect 15744000 Gebrauchsanleitung, Montageanleitung Seite 14

92594000 97980000
96525000
(M5x20)
98133000
SW 4 mm
(16x2)
95758000
94073000
98156000
(36x2)
98197000
(20x1,5)
98282000
98146000
(25x1,5)
98913000
92146000
(M34x1,5)
(25x2,5)
SW 27 mm
98471000
(44x4)
92617400 /
958430000
92617600
SW 3 mm
13597000
95521000
(22 mm)
(1°)
98368000
(M28x1,5)
SW 19 mm
92219000
98793000
(Ø 145 mm )
92216000
92234000
92579450 /
92579610
92215000
98133000
92272000
(16x2)
13595000
(25 mm)
Serviceteile
92540000
96454000
(M5x55)
13593000
98471000
(44x4) 92218000
95843000
SW 3 mm
98471000
(44x4)
92218000
92218000
958430000
SW 3 mm
92215000
(22 mm)
92218000
92215000
71
