TS 92 18-EC
■ As soon as the auto-stop sensor (O-3)
detects that the cut is finished, the saw will
stop automatically.
■ After the table saw stops cutting, the auto-
stop indicator (5) will remain lit within 5
minutes. Turn on the saw again for the next
cut.
■ If the table saw stops cutting for more than
5 minutes, the auto-stop indicator (5) will
turn off. Press the auto-stop button (6) and
turn on the saw again to reactive the auto-
stop feature for the next cut.
WARNING!
If auto-stop fails to turn off the saw at the end
of the cut, examine the auto-stop sensor (O-3)
and wipe up liquid and remove saw dust from
it.
Variable-speed dial (see figure P)
This table saw is equipped with a variable-
speed dial (4). The speed can be adjusted by
simply rotating the variable-speed dial.
Battery level indicator (see figure
Q)
Press the battery level indicator button (10)
and the LEDs will light up for approximately
10 seconds to communicate the battery pack
charge level.
To check the current battery charge level,
please turn off the table saw first and then
press the battery level indicator button (10).
Dust extraction (see figure R)
This table saw comes with a dust tube (18),
vacuum adapter (24) and dust bag (23). To
install the dust bag (23) or dust tube(18),
push it onto the dust port (22).
To install the vacuum adapter (24), after
the dust tube (18) is installed, connect the
vacuum adapter (24) with the dust tube.
The vacuum adapter (24) accepts vacuum
hoses.
NOTE
Clean the dust bag (23) at the end of the
cutting session and before transporting or
storing the saw.
WARNING!
Be extremely careful with disposed dust.
Materials in fine particle form may be
explosive. Do not throw sawdust on an
open fire. Spontaneous combustion may, in
time, result from mixture of oil or water with
dust particles.
Smart guard system (see figure
S1-S3)
WARNING!
Always keep guards in place. Guards must be
in working order and be properly mounted.
A guard that is loose, damaged, or is not
functioning correctly must be repaired or
replaced.
■ The smart guard system (1) maintains its
functionality as a material spreader for
through-cuts.
■ For non-through-cuts, it is necessary to
replace the smart guard system (1) with
the included riving knife which acts as a
material spreader and the anti-kickback
device (2).
■ In the event that the riving knife cannot be
used for a specific cut or for use with a dado
blade, it should be removed.
Setting bevel angles (see figure T)
Loosen the blade bevel lock lever (9)
counterclockwise, slide the elevation wheel
(8) until the pointer is at the desired angle,
and tighten the blade bevel lock lever (9)
clockwise.
Work helpers (see figure U)
Some sawing operations will require the use
of additional work helpers.
■ Use push block when working with narrow
workpieces when you need to push close to
the saw blade.
■ Use featherboards for all non-through-
cutting operations where the protective
guard cannot be used.
Ripping (see figure V1-V4)
WARNING!
Make sure the rip fence is locked.
■ Hold the workpiece with both hands and
press it against the table.
■ Use push stick when the distance between
the fence and the saw blade is less than
150 mm.
■ Use a push block when this distance is less
than 50 mm.
