SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Warning
Double insulation
Wear eye protection
Wear ear protection
Wear dust mask
Laser radiation
Do not stare into beam
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or
retailer for recycling advice.
Circular saw with laser
1. LOCK-OFF BUTTON
2. ON/OFF SWITCH
3. LASER ON/OFF SWITCH
4. FRONT HANDLE
5. BASE PLATE ANGLE SCALE
6. BASE PLATE BEVEL LOCK
7. PARALLEL GUIDE
8. BASE PLATE
9. PARALLEL GUIDE LOCK KNOB
10. SPINDLE LOCK BUTTON
11. LASER GUIDE
12. OUTER FLANGE
13. LOWER GUARD
14. SAW BLADE*
15. BLADE BOLT
16. LOWER GUARD LEVER
17. VACUUM ADAPTER
18. REAR HANDLE
19. DEPTH OF CUT SCALE
20. HEX KEY
21. DEPTH OF CUT ADJUSTMENT LEVER
22. INNER FLANGE (See Fig. G)
* Not all the accessories illustrated or
described are included in standard delivery.
