INSTALLATION OF THE RECEIVER (DOORBELL):
1. The receiver is designed for indoor use only.
2. When running, it must be plugged in a 230V AC socket, with free space around it so that it is always accessible.
3. The transmission range (max. 200m) is influenced by local conditions such as the number of walls through which the signal passes, metal door
frames and other elements which affect the transmission of radio signals (presence of other radio devices operating at a similar frequency, such
as wireless thermometers, gate controls, etc.) Transmission range can decrease drastically due to these factors.
OPERATION
RINGTONE SELECTION
1. Repeatedly press the ringtone change button (4) located on the receiver.
2. Each press of the button will play a different ringtone. There are 36 ringtones to choose from. The last ringtone played is the one that will be
used.
SETTING THE VOLUME
1. You can set one of the 4 volume levels. Repeatedly press the (3) button on the receiver.
2. Each press changes the volume. Select the volume level that best suits your preferences.
LOGIN (Learning system)
1. Plug the receiver into a 230V AC socket.
2. Long-press the pairing button (3) on the receiver, for ca. 5 seconds.
3. The receiver LED will light up. Release the pairing button. The receiver will switch to self-learning pairing mode which lasts for 25 seconds. During
this time, press the ring button. The doorbell will ring and the transmitter is now paired with the receiver. This automatically ends self-learning
mode.
4. To pair multiple transmitters, repeat the process for each transmitter from step 1.
Note: the doorbell has an internal memory where it stores the codes of the currently paired transmitters for the event of a power failure. There is
thus no need to pair transmitters again after a power cut.
MEMORY CLEARING
1. Press and hold the pairing button (3) on the receiver.
2. Plug the receiver into a socket.
3. The LED of the receiver will light up after ca. 5 seconds. Release the pairing button.
4. The LED will turn off.
5. The memory of all paired transmitters will be erased.
MELODY ASSIGNMENT
1. Delete the memory of the receiver (see Memory Clearing).
2. Press and hold the pairing button (3) until the LED lights up.
3. Select the melody using the buttons (4).
4. Press the transmitter button.
5. To configure the second and next transmitter repeat steps 2 to 4.
SOME PROBLEMS AND SOLUTIONS
The doorbell does not ring:
- the receiver may be out of range – change the distance between the transmitter and the receiver. The range may be affected by local
conditions.
- the receiver is not powered – make sure the receiver is properly plugged into the socket and that the power is on.
CLEANING AND MIANTENANCE
The wireless digital doorbell is a sensitive electronic device. Therefore, it is necessary to observe the following precautions:
- the receiver is designed for indoor use in dry environments only,
- the receiver must be located in an easily accessible location for ease of handling and unplugging,
- periodically check the functioning of the receiver button,
- do not subject the button or the receiver to excessive vibrations and shocks,
- do not subject the button and the receiver to excessive heat, direct sunlight and moisture,
- to clean it, use a slightly moistened cloth with a little detergent, do not use aggressive cleaning agents or solvents.
Simplified declaration of conformity
Orno-Logistic Sp. z o.o. declares that the OR-DB-KF-134 compatible with directive 2014/53/EU. The full text of the EU declaration of conformity is available
at the following Internet address: www.orno.pl.
(DE) Batteriefreie Funkklingel ONDO AC
Kabellose und batterielose Funkklingel ist für die Anwendung in Häusern, Wohnungen, Büros, Krankenhäusern, Läden, etc. gedacht. Keine
Klingelinstalation ist erforderlich. Die Klingel dient zur akustischen und optischen Signalgebung. Empfänger wird direkt an die Steckdose (Netzwerk
~230V) angeschlossen, der Sender ist mit elektromechanischem Wandler betrieben, keine Batterien sind erforderlich. Das Drücken der Taste wird
durch eine blinkende LED angezeigt. Die Funktion „Learning-System" ermöglicht, zusätzliche Sender einfach einzuloggen. Beim Senden und
Empfangen des Signals wird die Funkfrequenz 433,92 MHz angewandt. Die Reichweite der Klingel im freien Feld beträgt bis zu 200 m. Der
Empfänger verfügt über eine 4-stufige Lautstärkeeinstellung von 60 bis 90dB und 36 polyphone Klingeltöne zur Auswahl.
INSTALLATION
MONTAGE DES SENDERS (TASTE)
1. Loggen Sie den Sender vor der Installierung in den Speicher des Empfängers ein.
2. Stellen Sie vor der Montage sicher, dass die Stelle, an der Sie den Sender anbringen möchten, die Kommunikation zwischen Sender und
Empfänger nicht behindert.
3. Führen Sie einen Schraubendreher in die Löcher auf der Rückseite des Senders ein und entfernen Sie die hintere Abdeckung.
4. Verwenden Sie für die Installation doppelseitiges Klebeband (im Paket enthalten) oder zwei Schrauben. Obwohl der Sender gegen äußere
Einflüsse resistent ist, empfiehlt es sich, ihn an einem geschützten Ort, z.B. in einer Wandnische, zu installieren.
5. Legen Sie die rückseitige Abdeckung an.
6. Drücken Sie die Taste, um die Melodie aufzurufen. Wenn Sie die Taste drücken, leuchtet die LED auf, was bedeutet, dass das Gerät das Signal
an den Empfänger übertragen hat. Im Inneren des Raumes hören Sie eine vorprogrammierte Melodie.
5
