Application Examples - Siko MA504/1 Zusatz Zur Originalmontageanleitung

MA504/1-S

Application Examples

9 Application Examples
Length measurement
Required: Display accuracy 1/10 mm. Display shall be zeroed via function
key.
Designation
Resolution
Decimal point
Reference value
Offset
Counting direction
Switch-off method
Delayed reset function
Reset function enable
Increm. meas. function enable
Reference value change enable
Offset correction enable
Language
Angle measurement
Required: display range 0 ... 360°; display accuracy 1/10°. Display to be
zeroed via front key. Automated device switch-off after 0.5 h.
Conditions: circular disk with ø300 mm; resulting total circumference: U =
π x 300 mm = 942.48 mm
The programmable factor is calculated as follows: FAc = total display range
[1/10°] / circumference [1/100 mm]
3600 / 94248 = 0.03820
Designation
Resolution
Calculation factor
Decimal point
Reference value
Offset
Counting direction
Switch-off method
Switch-off time
Delayed reset function
Reset function enable
MA504/1-S · Date 10.05.2016 · Art. No. 85794 · Mod. status 242/15
Display
rES
dP
rEF
oFS
dir
Auto
4_Abs
F_Abs
F_rEL
F_rEF
F_oFS
LAn
Display
rES
FAc
dP
rEF
oFS
dir
Auto
PEriod
4_Abs
F_Abs
English 17
Progr. value
0.1
0.0
00000.0
00000.0
uP
oFF
oFF
on
oFF
oFF
oFF
E
Progr. value
FrEE
0.03820
0.0
00000.0
00000.0
uP
on
0.5
oFF
on
