INVENTOR AR5VI-09WiFi Installationshandbuch Seite 8

2
Installation Summary - Indoor Unit
1 2
15cm (5.9in)
12cm 12cm
(4.75in) (4.75in)
2.3m (90.55in)
Select Installation Location Determine Wall Hole Position
(Page 11) (Page 12)
3 4
Attach Mounting Plate Drill Wall Hole
(Page 12) (Page 12)
Page 8
 
