ENGLISH
NOTE: This instruction manual contains essential information about the safety measures to be adopted when the pro-
duct is being installed, operated for the first time or maintenance work carried out on it. Therefore, both the service
engineer and the user must read the instructions carefully before beginning installation and start-up. Keep this manual
for future reference about how this product works. This manual may be read on and downloaded from the website at
www.astralpool.com
To achieve optimum performance of the LumiPlus Mini, follow the instructions provided below:
1. VERIFY THE CONTENTS OF THE PACKING:
The following accessories are included inside the box:
QUICK COUPLING LUMIPLUS MINI LIGHT:
76682 - 76682WW - 76683
• Unit floodlamp
• Decorative cover
• O'ring
• Installation and maintenance manual
• Manual for electrical connection

2. GENERAL CHARACTERISTICS:

This floodlamp is a Class III electric apparatus with very low safety voltage.
The floodlamp complies with IPX8 degree of protection (resistance to penetration of dust, solid bodies and humidity) at a nominal
immersion depth of 2 m.
This floodlamp complies with international safety standards for lights, especially the EN 60598-2-18 standard: LIGHTS PART 2:
SPECIFIC REQUIREMENTS SECTION 18 LIGHTS FOR SWIMMING POOLS AND SIMILAR APPLICATIONS.
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric components which have
been inserted or handled at locations other than its own premises.
3. INSTALLATION:
• In order to clearly light a pool it is recommended to install a floodlamp every 5 m2 of water surface. In swimming pools which are
especially deep, a floodlamp is required for every 10 m3 of water volume.
• In order to prevent glare, the floodlamps should be installed so that they face away from the residence or usual view of the
swimming pool.
• In the event that lighting is used in training or competition pools, the floodlamps should be installed on the sides to prevent glare on
the swimmers.
• To avoid the need to empty the pool to change the lamp, we recommend that the floodlamp be installed in areas which are
accessible from the upper edge of the pool.
• Sealing all sections with resin systems or safety connections that comply with the IP68 rating is recommended to ensure that both
cables and cable sheaths are properly sealed. Failure to follow these steps may cause short- or long-term damage to the light and
installation cables.
4. ASSEMBLY:
Quick coupling LumiPlus Mini light
This light is manufactured for installation in guiding tube.
1. Install the wall conduit in the concrete wall, at a distance of 400-700 mm. below the water level (Fig. 1).
2. The wall conduit must be extended with a cable conduit the length of which remains above the maximum level of the swimming
pool or spa (Fig. 3).
3. Feed the light cable through the conduit (Fig. 4). Leave enough length of cable in order to be able to remove the floodlamp to the
border of the swimming pool (Fig. 2).
4. Then fit the light itself, pushing it into place (Fig. 5).
Spot LumiPlus Mini light for niche
After the housing has been installed, then assemble the floodlamp.
Insert the cable in the cable duct. Then, tighten the nut on the cable duct. Take the precaution of leaving 1.5 m of cable wound on the
body of the floodlamp in order to be able to remove the floodlamp to the edge of the pool in the event that handling is required (Fig.
6).
Insert the entire floodlamp assembly in the housing and secure it (Fig. 7).
5. MAINTENANCE:
This projector does not require any type of maintenance. If the projector is not working properly, please contact our customer
attention department.
THIS PRODUCT DOES NOT CONTAIN ANY ELEMENTS THAT CAN BE HANDLED, DISMANTLED OR REPLACED BY THE USER. IT IS
FORBIDDEN TO ACCESS INSIDE THE PRODUCT, OTHERWISE THE GUARANTEE OF THE PRODUCT WILL BECOME INVALID.
LUMIPLUS SPOT MINI LIGHT: 76680 - 76680WW - 76681
(These models of projectors need the niche that is available separately)
• Unit floodlamp
• Key for Mini light
• Installation and maintenance manual
• Manual for electrical connection
