Note: The image may differ from the actual product.
Typical Network Topology
■ Managed Mode
Via Centralized Management Software
A computer running the centralized management software, which can be in the
same or different subnet with the APs, is used to centrally manage the APs.
You can get the corresponding software from our website http://www.tp-link.com�
Via Wireless Controller (for CAP only)
The wireless controller can be in the same or different subnet with the APs� The
management host is used to log in to the wireless controller to centrally manage
the APs�
Internet
Router
Internet
Router
Switch
Management Host
Switch
Wireless Controller
5
Outdoor AP
Outdoor AP
Management Software
Outdoor AP
Outdoor AP
Host
English
