Operating instructions for Mapress pressing collar and adapter for pressing collar
3
Ensure that the sliding segments move freely and that the marks (1)
on the sliding segments (2) and the shells (3) form a line
With pressing collar ø76.1 - 108 mm: The pressing collar is
correctly positioned when the centring plate is pointing towards the
pipe.
4
Fit the pressing collar around the pressfitting and ensure that the
pressing contour of the pressing collar is positioned on the fitting
bead
1
2
3
