2. Release the On/Off trigger, otherwise the rotating direction button (4)
cannot be pressed. Use the rotating direction button to switch between
clockwise and counter clockwise rotation. With the rotation direction button
in the central position the trigger is locked and cannot be pressed. Use this
position before you put the machine down, to avoid unintentional starting.
3. Important! The machine has to come to a complete stop before the
rotating direction button can be used, otherwise the machine may be
damaged.

Inserting the Tool Bits

Important! Always remove the battery before you change the drill or screw bit
to avoid unintentional starting of the machine.
The cordless drill has a keyless drill chuck (3) so you do not need a key to lock
the tool bit in place. Make sure that the drill or screw bit is not skew when it is
inserted and the chuck tightened.
1. Before inserting drill or screw bits
open the jaws of the chuck by
holding the lower ring of the
chuck and turn the locking ring
counter clockwise.
2. Open the chuck until you can
insert the tool.
3. Insert the drill/screw bit all the way in and then, holding the lower ring, turn
the locking ring clockwise to tighten it.
4. To remove the tool, hold the lower ring of the chuck and turn the locking
ring counter clockwise. Open the chuck until you can remove the tool.
Operation
9
