Turn off and unplug machine before calibration to prevent unexpected startup.
WARNING!
When checking the blade level with the PROSHARP blade angle tester, if it is off-center, your machine
may be out of calibration. First try running more cycles as your skate blade may have been un level
to begin with. If the problem persists, adjust the manual wheel calibration nut accordingly to find the
center of the blade again using the manual adjustment tool (shown on page 5) provided with purchase.
1. Insert the 2mm hex wrench into the bracket hole
as shown and turn it counterclockwise for one
full rotation.
2. Place the adjustment tool into the hexagonal
adjustment nut located inside the machine.
3. Rotate the adjustment tool counterclockwise
to adjust the grinding wheel towards the door
direction, and clockwise to adjust it in the
opposite direction.
4. After completing the adjustment, use the 2mm
hex wrench to tighten the bolt clockwise.
5. After the adjustment is done, test grind the
ice skate to confirm if the desired accuracy is
achieved. If the ice blade still doesn't meet the
requirements, repeat steps (1-4) to complete
the adjustment.
Scan the QR code to get a further step-by-step
guide or consult your PROSHARP App.
1. To create a new user, go to the user menu
by selecting the "USERS" button at the
bottom left of the touch screen.
2. Select "Create new user" at the top of the
menu.
MACHINE CALIBRATION
HOW TO STORE A USER PROFILE
3. Input a name then select your preferences
for wheel hollow, number of cycles and
the type of blade (player or goalie)
4. Make sure you select "SAVE" at the
bottom of the user preferences menu.
