Prosharp BAUER ADVANTEDGE Maschinenhandbuch Seite 8

Using the HMI Touch screen, select either "Guest/Player Blade", "Guest/Goalie Blade" or any user
that was previously saved (see Create User Information section).
1. Put the skate in the machine with the heel
towards the HMI touch screen.
Pinch hazard! Be sure nothing but the skate
blade is in the slot when clamping. Press
on the HMI touch screen and wait
"CLAMP"
until the motor has stopped.
2. Select the number of passes using the +/-
symbols on the HMI touch screen. You may
sharpen up to 10 cycles at a time- depending
on your need.
A. Average is 4 cycles.
B. First time skates or skates with bad
nicks OR changing hollow depth could
require up to 10 cycles.
3. Press the
"START"
screen.
WARNING!
Check that no loose items are in or near
the skate slot (for example, laces, clothing,
jewelry, or hair). Motor package will do a
'dry pass' to determine the length and height
of your blade, protecting your profile with
specific entry and exit points.
*You can always unclamp
your skate by pressing the
left unlock icon
08
HOW TO SHARPEN YOUR SKATE BLADE
WARNING!
button on the HMI touch
Entanglement hazard!
4. After skate is done sharpening, machine LED
lights will turn green and HMI touch screen.
will indicate,
"SHARPENING COMPLETE"
Skate will unclamp automatically.
5. Press
"CONTINUE"
screen to go back to Home Screen.
Skate is sharp! Use caution
WARNING!
when handling. Protective gloves are
recommended for steps 6 & 7 below.
6. Deburr the skate safely with a PROSHARP
hone (not included) by pressing the honing
stone against the face of the skate blade.
With light pressure, press down on the
lower side of the stone and slowly run the
stone back and forth along the edge of
the blade for 2-4 full passes. Repeat on
the opposite side. ALERT- When deburring
coated steel, make sure to only use the X-5
or X-3 Combi Hone on the porcelain side or
Gummi Hone (not included) to ensure you
do not remove or damage the coating. Visit
www.bauer.com/prosharp
7. Check level using a PROSHARP blade angle
tester (not included).
on HMI touch
to learn more.
.
