Product Description - BaSt-ING ValRemote Bedienungsanleitung

2.

Product description

(4)
(1)
start button
(2) indicator light
(3)
IR transmitter
(4) IR receiver
(5)
connection cable – machine
(5)
(9)
(6)
connection cable – felling wedge
(7) magnet
(8)
reed sensor
(9) pipe clamp connection
– 11 –
(3)
(8)
(2)
(1)
(6)
(7)
