CAUTION: TURN THE GAS OFF AT THE
GAS SUPPLY, BEFORE STARTING.
1.
2.
3.
3.
Match end of alignment tool with valve stem by looking down barrel of tool (a).
Push alignment tool onto valve stem (b).
While holding control knob bezel, gently push alignment tool down.
Tool must freely return to up position.
1.
Loosen Screws.
2.
Make sure bezel moves freely
in all directions.
KNOB BEZEL
ADJUSTMENT INSTRUCTIONS
TOOLS
NEEDED:
Alignment Tool
4.
5.
6.
Phillips Screwdriver
Knob Bezel
4.
Once aligned, continue to hold
control knob bezel
and tighten screws. Push tool
again to check for
free movement.
5.
Remove alignment tool.
6.
Install knob onto valve stem and
test for free movement.
Readjust if necessary.
50451 12/28/06
