3
Changing the fi- IMPORTANT! When fitting the Robacta Drive CMT flex (22° / 36°) fixing bracket,
xing bracket ensure that the installation marker for the desired angle matches the installation
marker on the Robacta Drive CMT (TCP in 6th robot axis).
* Torque: 2,4 Nm
1
Replace Wear
Parts on Torch
Neck
Risk of scalding due to hot coolant.
This can result in serious personal injuries.
▶
IMPORTANT! Do not allow coolant to leak out. Pay attention to the following
points when removing the pipe bend from the Robacta Drive coupling point:
-
-
-
-
AlMg 100-150N
2
1
CAUTION!
Turn mains switch on power source to - O - position prior to removing torch
neck.
Cut welding wire to length by the contact pipe
Press pipe bend in and hold it
Completely undo the swivel nut
With a quick movement, pull the pipe bend straight off
4
Fe, CrNi, CuSi 150-200N
2
1
°
2 2
2
*
