4
ESC Button
5
Button
6
LCD Display
7
USB Port
8
TF card slot
3.2 Specifications
1) Screen: 4.0" TFT, 480*320 LCD display
2) Input voltage range: 9~18V
3) Operating current: < 500mA
4) Power consumption: < 4W (Typical)
3) Operating temperature: 32°F~122°F / 0°C~50°C
4) Storage tempetature: -4°F~158°F / -20°C ~70°C
5) Working humidity: < 80%
6) Outline dimension: 200*100*27 mm (L x W x H)
7) Weight: < 400g
3.3 Accessories
1) Main Unit
2) Main diagnostic cable
3) User's Manual
4) USB cable
5) TF card
6) TF card reader
All manuals and user guides at all-guides.com
iCarsoft English User's Manual
Exit the current program or return to
the previous screen.
To retrieve the DTCs in the database.
Indicates test results.
To connect to PC to upload data or
print test results.
Insert the TF card into it to update your
tool.
EN
7
