Alevo
| Rollator
Locking brake
•
Press down on both brake levers to activate the locking device (Fig.
12).
•
To release the locking brake pull both brake levers back into middle
position.
Adjusting the brakes
12.
The brake is set properly, if the brake pins do not touch the wheel and the
locking brake can be activated easily.
•
You can adjust the brake for harder or softer action by pressing in and
then rotating the protective cap (Fig. 13).
•
If the wheel can still be moved despite the activated brake, you need
to adjust the brake for harder action. To do so, turn the protective cap
(Fig. 13) on the brake mechanism in a counter-clockwise direction.
•
If the brake rubs, you need to adjust the brake for softer action. To
do so, turn the protective cap (Fig. 13) on the brake mechanism in a
clockwise direction.
13.
5.7. Wheels and tyres
Your rollator is equipped with flat-proof wheels (see sec. 6).
5.8. Tipping Aid
The tipping aid is intended to make it easier for users to overcome curbs
and small obstacles.
Step on the tipping aid with your foot (Fig. 14) and at the same time pull
on the push handles. The front wheels lift slightly off the ground and with
14.
a little force you can push the rollator slightly past the obstacle.
40
Caution! Make sure the rollator is positioned on level
ground when using the tipping aid.
5.9. Accessories
5.9.1. Cane holder (optional)
The optional cane holder can be attached with only a few simple steps.
You can place both parts of the cane holder easily on the frame of the
rollator (Fig. 15).
5.9.2. Sun-/ rain umbrella
An umbrella is available for your Alevo to protect you from the sun or
rain.
5.9.3. Bottle holder
A bottle holder can be attached to the Alevo for transporting a bottle.
5.9.4. Profiled tyres
If desired your Rollator can be equipped with profiled tires, it provides
stability and grip on unpaved and uneven surfaces such as dirt roads,
forest floors or cobblestones. The Alevo Country is already equipped with
tread tyres as standard.
5.9.5. Hercules Lock
A lock is available to secure your Alevo after parking.
Bischoff & Bischoff GmbH | 2024.04.23 - Revision: 2
Alevo
Rollator |
15.
41
