EN
Edge Trimmer
Translation user manual
59G718
CAUTION: BEFORE USING THE POWER TOOL READ
THIS MANUAL CAREFULLY AND KEEP IT FOR
FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
• Hold the power tool by insulated gripping surface
only, because the cutter may contact its own cord.
Cutting a „live" wire may make exposed metal parts of the
power tool „live" and could give the operator an electric
shock.
• Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by your hand or against the body leaves it unstable
and may lead to loss of control.
• Cutter bits must match exactly to holder of the power
tool. Mismatch of the working tool and the power tool holder
causes irregular rotation, strong vibrations and may cause
loss of control over the power tool.
• Rotary speed of working tools must not be lower than
maximum rotary speed specified for the power tool.
Equipment subjected to greater rotary speed may get
damaged.
• Hold the plunge router by both handles during
operation, keep stable body position. Power tool is safer
when held with two hands.
• Do not touch rotating cutter bit or put hands in area
of the bit operation. Keep your second hand on the
additional handle. Guiding the device with both hands
reduces risk of cutting hands with the working tool.
• Wear personal protection equipment. Depending on
type of work, wear protective mask, goggles, protective
glasses and hearing protectors. Protect eyes from
particles produced at work and floating in the air. Anti-dust
mask provides protection of respiratory tract and must filter
out dust produced at work. Prolonged exposure to noise
may lead to hearing loss.
• Dust of certain wood types may be dangerous to
health. Direct physical contact with dusts may cause
allergic reaction and/or respiratory system diseases of
operator or bystanders. Dusts of oak and beech are
considered carcinogenic, especially in connection with
wood
processing
substances
Therefore use of anti-dust mask, dust extraction systems
and appropriate ventilation is recommended.
• Clean ventilation holes of the power tool on regular
basis. Motor blower sucks dust into casing and large
depositions of dust may cause electric hazards. Do not use
power tool in proximity of flammable materials. Sparks can
cause ignition.
• Do not use damaged or blunt cutter bits. Blunt or
damaged cutter bits increase friction, can cause jamming
and reduce material processing quality.
• Do not touch the cutter bit immediately after the work
has been finished. This element may be hot and may
cause burns.
• Start the power tool before the cutter bit gets into
contact with the processed piece. Otherwise there is a
risk of kick back, because used tool can jam in the
processed piece.
• Ensure all locking clamps are tightened.
• Never attach working tools other than recommended by
the manufacturer to the power tool.
• When changing the cutter bit, make sure its shank is held
by at least 20 mm of its length.
• Prior to cutting ensure that there is enough free space
under processed material to prevent contact of the cutter bit
and other objects.
• Check surface of the working area. Make sure there are
no unwanted objects (nails, screws etc.).
(wood
impregnants).
• Do not leave the router unattended when switched on.
• When the power tool is not in use, always keep it
disconnected from the power supply and stored in a place
beyond reach of children.
• Always disconnect the power tool from power supply prior
to commencing any activity related to its adjustment,
maintenance or operation.
• When cleaning the power tool do not use any solvent that
might damage plastic parts.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures
and additional safety systems are used, nevertheless
there is always a small risk of injuries at work.
SYMBOLS
IMPORTANT: Some of the following symbols may be used
on your tool. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to
operate the tool better and safer.
Symbol
Name
V
Volts
A
Amperes
Hz
Hertz
W
Watt
Min
Minutes
ϕ
Diameter
n
No load speed
0
.../min
Revolutions
reciprocation per
minute
Alternating
current
Direct current
Alternating
direct current
Class
construction
Earthing terminal
SPECIFICATIONS
Parameter
Model
Voltage
Rated input power
No load speed
Chuck Size
Safety class
Weight
OPERATING INSTRUCTION
WARNING: Before adjusting the function of the tool, please
make sure the tool is off and the plug does not connect to
the electricity.
Designation
/
Explanation
Voltage
(potential)
Current
Frequency
(cycles
per
second)
Power
Time
Size of drill bits,
grinding wheels,
etc.
Rotational speed
at no load
or
Revolutions,
strokes,
surface
speed, orbits etc.
per minute
Type
or
a
characteristic
of
current
Type
or
a
characteristic
of
current
or
Type
or
a
characteristic
of
current
II
Designates
double insulated
construction
tools.
Grounding
terminal
Value
59G718
230V / 50Hz
510 W
30000 RPM
6, 8 mm
II
1,64 kg
