English
3. Usage and Operation
Install and Dismantle the Anti-tipper
Pull the switch to install or uninstall the anti-tipper (Picture 8 and 9).
Before the first use, please adjust the anti-tipper to a proper
setting that won't allow the wheelchair to tip backwards.
When this wheelchair is delivered to you, the anti-tipper is
preset to the highest position which does not provide any anti-tip func-
tionality. With the wheelchair in the unfolded position, pull the switch to
lower the anti-tipper shaft to the desired position.
Castors
Front castors and wheel bearings should be checked periodically and
lubricated if needed.
Leg rests (Footrest) Installation
Lock the rotation shaft in footrest tube, lift the footrest puller, and
rotate the footrest from outside to the to the middle so that the footrest
bar is pointing forward. When the footrest puller locks into place, the
footrest is in the proper position to use the wheelchair (Picture 10).
The footplate is height is adjustable at 25mm per level. User can
select a comfortable height then secure the footrest in the desired
height (Picture 11). To adjust the height, use a hex wrench and un-
screw the hex bolt. Adjust the footplate to the desired height. Reinsert
the hex bolt and tighten.
Do not use the wheelchair if the footrest puller is loose or not
locked into place.
Picture 8 Picture 9
