9. Usage of 3D-LCD-Glasses

If you want to see the image stereoscopically by the means of wired 3D LCD
Glasses we recommend the usage of a CRT VGA monitor, which enables to show
the VGA signal at 85Hz flickerfree. Take care about the right phase-setting by
changing switch „PHASE" A/B.
By the reason that LCD monitors are too sluggish, these displays are not suitable
for stereoscopic displaying with 3D LCD Glasses.
If you like to use wireless 3D LCD Glasses, we recommend our 3D Blaster and to
connect it to the „SYNC OUT" of the 3D VGA ENCODER.

10.aunching the 3D LCD Glasses

Wired 3D LCD Glasses (Optionally available)
Plug the stereo jack of the wired 3D LCD Glasses to the „Wired glasses" output.
To connect more wired 3D LCD Glasses (max 15) in parallel, you could use 3-
pole 3.5mm plug Y-splitter.
Y-Splitter (Optionally available)

11. Turning off

The 3D VGA ENCODER can be deactivated by the On/Off switch.
This switch disconnects the 3D VGA ENCODER completely from the power
supply, the power supply output „DC OUT" is not getting divided from power.
24
