7. Launching

Turn the 3D VGA ENCODER switch ON/OFF in position OFF.
At stereoscopic recordings the 3D VGA ENCODER gets used as signal
transformer for the control monitor. Place the 3D VGA ENCODER so that the two
cables of the cameras are able to reach the 3D VGA ENCODER optimally.
You can also mount the 3D VGA ENCODER behind the control monitor and by
that using a short VGA cable.
Connect the two video cameras by the means of S-Video or Chinch cable to the
inputs „VIDEO-A IN" / „VIDEO-B IN". If you want a Composite FBAS signal using
a Chinch cable, you can apply the delivered S-VIDEO/Chinch adapter cable.
Connect the control monitor to the 3D VGA ENCODER via a VGA cable.
The power supply has to be connected to the „DC IN" input. You can use the
delivered voltage converter or an accumuluator with a DV Plug.
Turn on the 3D VGA ENCODER by pressing ON.

8. Description of the features

When the 3D VGA ENCODER is able to receive a videosignal, it converts it into a
VGA signal, what is shown on the control monitor.
Depending on the selected setting, the signals are differently displayed.
If the 3D VGA ENCODER cannot reiceive a videosignal at an input, you will see a
black image with a white frame on this channel.
The next task is it to adjust the display details to the control monitor display.
Therefore there are some buttons available.
Activate the video inputs and start the adjustment.
You should keep one button pressed and with the other buttons (+) / (-), so up
/ down adjust the image to the control monitor.
Described features can be influenced by following buttons:
• Horiz.Setup Left: Left image init, for it (+ / -)
• Horiz.Setup Ratio: Horizontal image size, for it (+ / -)
• Vert.Setup Up: Upper image init, for it (+ / -)
• Vert.Setup Ratio: Vertical image size, for it (+ / -)
• Brightness A: Brightness at Video-A, for it (+ / -)
• Contrast A: Contrast at Video-A, for it (+ / -)
22
