6.4 Operating modes (expert)

The bar has 4 operating modes:
1 Fixed
The bar has a fixed ionisation. Ionisation works like a EasION bar. A fixed number of positive
and negative ions are produced. Depending on the application, the static charge will be
neutralised and residual charge will remain.
2 Manual
For test applications or very specific applications the ratio between positive and negative ions
can be set manually. This is done by entering a ratio number. Usually, an even number of
positive (+) and negative (-) ions will be produced = 50/50 (fixed).
By entering a number other than 50, e. g. 60, 60 % positive and 40 % negative ions are
produced.
3 CLFB (Closed Loop FeedBack)
For this mode a Sensor bar IQ Easy bar has to be connected to the platform. After the film or
object to be neutralised has passed the EasION, the sensor will measure the residual charge.
This value is communicated to the ionisation bar which will regulate the ratio of positive and
negative ions automatically, so that the residual charge will be as close to neutral (0) as
possible.
4 Auto tune (not yet available)
To select the different modes, go to expert mode 6.2
(if not selected earlier):
- Click on the Information tab of the
EasION IQ 4.0
[
- Click on the settings button
- Click on Operation mode
- Select the desired operation mode
(Auto tune is not available at this time)
