NV350 Instruction Manual
Model: NV350 KISE5V 12/12DB 5B (X00004#, where # can be any number of characters)
Maximum outputs: 250W max.
Comments: PSU has a 45° angle fan fitted at the output end producing reverse air flow. Output cables of 12 to 24
AWG, which have a maximum length of 500mm, are supplied with this model. The chassis is 75mm longer in length
compared to the standard chassis. See model on page 28.
Compliant with EN/IEC/UL/CSA 60950-1 only
Model: NV350 LISIS5V 3.3B 12BH 5/15DB (K30068X, where X can be any character)
Maximum outputs: 201.4W max.
Comments: PSU has fixed, reduced speed fan set to 5.5V.
Compliant with EN/IEC/UL/CSA 60950-1 only
Model: NV350 LIS 15/15DB 12/12DB 5.25/12DB (K30073A)
Maximum outputs: 15V,3A; 15V,2A; 12V,6A; 12V,2A; 5.25V,9A; 12V,2A
Comments: PSU has fixed, reduced speed fan set to 5.5V.
Compliant with EN/IEC 60950-1 only
ELECTRICAL & THERMAL RATINGS:
Input Parameters
Standard
Nominal input voltage (V)
Input voltage range (V)
Input frequency range (Hz)
Maximum input current (A)
Inrush Current (A)
For input voltages between 85 and 89.9V the output power is derated to 94% of the values given in the Cooling
Options Table.
Output modules:
Module
Output Voltage
3.14-3.6V
4.75-5.5V
B
7-9V
12-15.5V
24-28V
12-15.5V
BH
24-28V
12-13.2V
15-16.5V
C
24-26.4V
27-32V
CM
24-26.4V
DA CH1
11.88-12.25V
-11.9 to
DA CH2
-11.6V
3.14-3.6V
4.75-5.5V
DB
5.5-6.5V††††
CH1
12-15.5V
24-28V
3.3-6V‡
DB
7-15.5V
CH2
24-32V
60950-1/61010-1/62368-1
100 - 240
85 - 264
47 - 440
5.5
Occupied
Maximum Average Current According to Slot Position (A)
Slots
Slot 1
40
40*
2
22.5**
16***
8****
20#
2
10##
33.34†
26.67†
3
16.67†
14.82††
16.67†††
3
-
-
1
-
25
25
25
13¥¥¥
2
7¥¥¥¥
10
5
2
Page 17 of 30
<15
Slot 2
Slot 3
-
40
-
40*
-
22.5**
-
16***
-
8****
-
20#
-
10##
33.34†
-
-
26.67†
-
16.67†
14.82††
-
16.67†††
16.67†††
-
-
-
-
-
25
-
25
-
25
-
13¥¥¥
-
7¥¥¥¥
-
10
-
5
-
2
60601-1
100 - 240
85 - 264
47 - 63
5.5
Slot 4
Slot 5
40
40
40*
40*
22.5**
22.5**
16***
16***
8****
8****
20#
20#
10##
10##
33.34†
-
26.67†
-
16.67†
-
14.82††
-
-
-
3¥
-
1¥¥
25
25
25
25
25
25
13¥¥¥
13¥¥¥
7¥¥¥¥
7¥¥¥¥
10
10
5
5
2
2
17158 issue 34, October 2022
