5.3 WIRING CONNECTION DIAGRAM

Wire the mSLW-02 to the power supply system as shown
in the diagram.
12÷24 V
STEP 3
connect the power
input wiring
/ 4 x 2 A
mSLW-02
+
W W W
31
3
W
