IR remote control
The IR remote control buttons are similar
to those on the front panel. Place the two
AAA batteries in the remote control.
To connect the remote control to the
DVR:
1. Press Menu on the front panel or
right-click the mouse and select
Menu. The main menu screen
appears.
2. Select Display mode settings
Monitor.
3. Check and remember DVR device
address value. The default value is
255. The device address is valid for
all IR controls.
4. On the remote control press the
Device button.
5. Enter the device address value. It
must be the same as that on the TVR
42.
6. Press ENTER on the remote or front
panel.
USB mouse
The USB mouse provided with the
TVR 42 operates all the functions of the
DVR, unlike the front panel, which has
limited functionality. The mouse lets you
navigate and make changes to settings
in the user interface.
Connect the mouse to the DVR by
plugging the mouse USB connector into
the USB port on the front panel. The
mouse is immediately operational and
the pointer should appear.
Web browser control
The TVR 42 Web browser lets you view,
record, and play back videos as well as
manage all aspects of the DVR from any
PC with Internet access. The browser's
easy-to-use controls give you quick
access to all DVR functions.
EN : 4
All manuals and user guides at all-guides.com
To access the unit, open a web browser
and enter the IP address assigned to the
DVR as a web address. In the log on
screen, enter the default user ID and
password:
•
•
The default values for TVR 42 network
settings are:
•
> •
•
•
•
Figure 4: Web browser interface
Live view mode
Live mode is the normal operating mode
of the unit where you watch live pictures
from the cameras.
Regularly used functions in live view can
be quickly accessed by clicking the left-
button of the mouse on the camera
image. The shortcut pop-up toolbar
appears. See Figure 3 on page 2 for a
description of the functions available.
User ID: admin
Password: 1234
DHCP: Enabled by default.
IP address - 192.168.1.82
Subnet mask - 255.255.255.0
Gateway address - 192.168.1.1
Ports:
When using the browser:
RTSP port: 554
HTTP port: 80
When using TruNav:
RTSP port: 554
Server/Client software port : 8000
