Multi 3310 IDS
Display (example: pH measurement)
3
2
AutoCal TEC
1
HOLD AR
Info
Jack field /connections
1
3
Initial
commissioning
ba77142y01 08/2015
01.07.2011
USB output
08:00
2
1 Insert the supplied batteries.
Make sure that the poles are in the correct position.
2 Connect the power pack if necessary.
3 Switch on the meter with the <On/Off> key.
Caution
Follow the safety instructions of the used sensors.
The operating manuals of the sensors are available on the supplied CD and on
the Internet under www.WTW.com.
1 Status information
4
2 Measured value (with unit)
3 Measured parameter
4 Sensor symbol
(calibration evaluation)
5
5 Measured temperature (with unit)
6 Further status information
6
7 Softkeys and date/time
7
1 Digital sensors
(pH, conductivity, D.O.)
2 USB B interface (device)
3 Connection for line adaptor
4 Service interface
EN
English
