Dimension; Datas - Wamsler TOMO 18813 Bedienungs- Und Aufstellungsanleitung

TYP 18815

3.2 Dimension

Art.No.
G001881310
G001881410
G001881510
The dimension information shown is only for information! We reserve the right to make changes to the
construction if these improve the technical level or the quality!

3.3 Datas

Typ
Nennwärmeleistung
Heating capacity (m
-under favourable
-less favourable
-not favourable heating circumstances
according to 18893/TAB2 DIN standard
Flue gas values:
Flue gas stream:
Flue gas temperature:
Min. pressure at nominal performance:
CO (relating 13% O2):
Dust (relating 13% O2):
Efficiency:
Energy efficiency class
All information provided by the exhaust gas values are based on the EN 13240 under stationary labor-
atory conditions. We reserve the right to make changes which relate to technical advances and / or to
an improvement in quality. We accept no liability for printing errors and changes which occur after
printing.
width
(mm)
652
450
410
3
)
fuel:
draught height
(mm) (mm)
372 768
475 1050
364 800
18813
TOMO
9 kW
200
120
82
Scheitholz
7,3 g/s
325 ˚C
12 Pa
≤ 40 mg/m³
≤ 1250 mg/m³
≤ 0,10 %
≥ 76%
A
28
weight weight
netto brutto
(kg) (kg)
157 175
135 153
72 90
18814
OKU
7 kW
144
84
58
Scheitholz Scheitholz
6,0 g/s
332 ˚C
12 Pa
≤ 40 mg/m³ ≤ 40 mg/m³
≤ 1250 mg/m³ ≤ 1250 mg/m³
≤ 0,10 %
≥ 79%
A
18815
ROCKY
7 kW
144
84
58
5,6 g/s
318 ˚C
12 Pa
≤ 0,10 %
≥ 78%
A
