1.3.5 VGA Port
1.3.6 Audio Jacks and Game/MIDI ports
Front Audio (J1)
1 Mic+
3 Vbias
5 AuD_R_Out
7 N. C.
9 AuD_L_Out
12
63900235 1.pmd
VGA Port
Game Port
Line-out
Line-in
Mic-in
2
1
Front audio
2 Ground
4 AuD_Vcc (Avcc)
6 N. C.
8 Key
10 N. C.
12
CN2
CN9
2 10
1 9
10
9
(J1)
