Basic Battery installation drawing
40 mm
3 option
operational
choices
OUT
Auxiliary
battery bank
Determines operational mode for unit
1) Automatic operation
2) Ignition feed
3) Regenerative braking ignition option.
See next page for information
regarding setup and application
Negative
Positive
F
A
Heat sink
N
12V
+
+
+
IN
Battery
Temp
Sensor
Page 4
optional
remote control
Absorption
Cond.
H Charge
Float
Sterling Power Products
V
12.2
In / Unit
Out / Rem
Audible alarm on/off
Batt.
hold > 3 sec
Temp
On / Off
Volts
Menu
hold>3 sec
Select
Change
Fault
Fuses. Fuses are there to protect
cable runs through bulkheads
etc. A fuse should be rated
to about 40-50% higher than the
maximum current expected. E.g for
a 60A product use about an 80A
fuse. The fuse should be within
200m of the battery.
ENGINE
STARTER
BATTERY
