Be very careful when shortening the silicone strap!
Shortening of the silicone strap should be carried out symmetrically and on a
step-by-step basis until the desired strap length has been achieved. If asymmetric
shortening is necessary, the body-facing side should be shortened more. Keep
trying on the silicone strap in between. Shortening on both sides by one hole in
each case corresponds to a reduction of the total size by 10 mm – a one-sided
length reduction of 5 mm.
Please note: To use the strap-length quick adjustment, the stud on the silicone
strap half without the SINN logo must always be in position 2 , a metal pin is
always located in position 1 . Use the stud to determine the margin for the strap-
length quick adjustment so that you will be able to compensate for a changed
wrist circumference (e.g. due to temperature-related variations). To use a mini-
mum margin, at least four positions should always be occupied on the silicone
strap half without the SINN logo, in the following sequence: Metal pin 1 , stud 2
and two additional metal pins 3
4 (see diagram).
4
3
2
1
First, shorten the silicone strap for the strap-length quick adjustment (without SINN
logo). To do this, sever the silicone strap with a knife or a pair of scissors centrally
between two boreholes. After severing the silicone strap, remove the stud and
replace it at position 2 after first removing the metal pin. All other boreholes must
be filled with a metal pin.
If a further shortening is necessary, you will then need to carry this out on the
other silicone strap half (with SINN logo). Sever the silicone strap again with a
knife or pair of scissors – centrally between two boreholes. After severing the strap,
replace the outermost metal pin at position 1 with the spring bar
reattach the folding clasp to the silicone strap. To do this, insert the silicone strap
half with the spring bar on one side into the hole in the folding clasp. Using the
strap replacement tool, press on the plate on the opposite side of the spring bar
to position it in the hole. Pull on it to check whether the folding clasp is secure.
A
Plate
A
and the
Plate
A
33
1
