1 Go into SETUP mode by pressing the FEED key
GB
before switch on the printer and going on to press
it for a few seconds after the printer power up.
2 The printer should print all list of the parameters:
•
RS232 Baud Rate
19200
D
, 9600, 4800, 2400, 1200.
•
RS232 Data length
(1)
•
RS232 Parity
: None
•
RS232 Handshaking
ware
D
.
•
Busy condition
•
USB Address Number
•
Autofeed:
CR disabled
•
Print mode:
Normal
•
Chars/Inch:
A=11 B=15 cpi, A=15 B=20 cpi
(3)
•
Speed/Quality
Speed.
•
Paper width
: 76mm [80 PaperW]
PaperW].
•
Notch alignment:
•
Notch Threshold
2.00
D
, 2.25, 2.50, 2.75.
•
Notch Distance [mm]
•
Total cut
(5)
: Disabled
•
PaperEnd Buffer Clear:
•
PowerFail WakeUp mode
Always OFF, Always ON.
•
Print Density:
-50%, -37%, -25%, -12%, 0
+25%, +37%, +50%.
Notes:
The parameters marked with the symbol
default values.
Note
(1)
: Parameter valid only on serial printer.
Note
(2)
: This parameter is displayed only for models with
USB interface; it's used to identify univocally the
USB printer by a numerical address code, if to the
PC are connected two printers that are the same
models, for example two Kube-U.
Note
(3)
: "Current consumption" parameter is not set by the
user but it depends on the "Speed/Quality" param-
eter in this way:
Speed/Quality
Low Speed
Normal Speed
High Speed
Note
(4)
: The parameter "Notch Distance" is displayed and
enabled only in case that the parameter "Notch
Alignment" is enabled. The parameter "Notch
Distance" is used to set the exact distance of the
notch entering the desired value in millimetre and
in deci-millimeter.
Note
(5)
: When this parameter is disabled, the printer always
executes a partial cut because the total cut com-
mand will be ignored; otherwise when is enabled,
the total cut command (Esc i) will be executed.
Note
(6)
: Using this parameter, when occurs a power fail the
printer can be switched on automatically, without
press On/Off key.
- "LAST PWR State": put the printer in the previous
state (ON or OFF) before a power fail;
- "Always ON": the printer always switch on auto-
matically, after a power fail;
- "Always OFF": the printer switch on only pressing
On/Off key, after a power fail.
(1)
: 115200, 57600, 38400,
(1)
: 7, 8
D
bits/car.
D
, even, odd.
(1)
: XON/XOFF, Hard-
(1)
: OffLine/RXFull, RXFull
D
.
(2)
: 0.
D
, CR enabled.
D
,Reverse.
D
D
: Normal
, High quality, High
D
, 80mm [82,5
D
Disabled
, Enabled.
(4)
: 0.75, 1.00, 1.25, 1.50, 1.75,
(4)
: 00.0
D
.
D
, Enabled.
D
Disabled
, Enabled.
(6)
: LAST PWR State
D
,+12%,
D
are the
Current consumption
Low Current
High Current
High Current
.
D
,
