15. Maintenance

• Remove the batteries from their cas-
ing and store them properly if you do
not intend to use the oximeter for a
lengthy period.
• Store the oximeter between 14°F and
104°F (–10°C to +40°C) and at levels
of humidity of between 10% and 95%.
• Check the oximeter regularly for damage.
• Do not use the oximeter in an envi-
ronment containing flammable gases
or use it in an environment where the
temperature or humidity is excessive-
ly high or low.
• Check the accuracy of the oxygen sat-
uration and pulse rate measurements
using an appropriate calibration device.

16. Technical specifications

01 Dimensions: 62.0 mm (Width)
× 37.0 mm (Depth) × 32.0 mm
(size) Weight: 42.5 g (includ-
ing two AAA dry-cell batteries)
E-IM-PO110-002.indd 11 E-IM-PO110-002.indd 11
02 Peak wavelength range of light
emitted by the probe: red light 660
nm ± 5; 940 nm ± 10 infrared light.
03 Maximum optical output pow-
er of the probe: 1.2 mw for
infrared light (940 nm).
04 Date of manufacture: see label
05 Normal working condition
Operating 5°C to 40°C
temperature (41°F to 104°F)
15% to 80%,
Relative humidity
no condensation
Atmospheric
70 kPa to 106 kPa
pressure
Voltage rating DC 3.0 V
06 Technical settings
SETTING VALUE
Oxygen
70% to 100%
saturation
Pulse rate 30 bpm to 254 bpm
SETTING VALUE
Oxygen
1%
saturation
Pulse rate 1 bpm
±3% (70% to 79%)
Oxygen ±2% (80% to 100%)
saturation No requirement
(≤ 70%)
± 1 bpm (≤100bpm)
Pulse rate
± 2 bpm (>100bpm)

17. Safety category

• Type of protection against electric
shocks: internally powered equipment.
• Level of protection against electric
shocks: type BF applied part.
• Level of protection against water pen-
etration. IP22
• Safety level for use in flammable anaes-
thetic mixtures with air, oxygen or
nitrous oxide: non-AP/APG
• No part of the oximeter's application
impedes the defibrillation load effect.
