NV350 PFC Handbook
Environmental Specifications:
Description
Use
Temperature
Humidity
Altitude
Pressure
Orientation
Material Group
Pollution Degree
Overvoltage Category
Class
Weight
IP Rating
* - 5000m for 60950-1 and 60601-1 Edition 3 only, 3000m for other standards applicable.
Level of Insulation:
Primary mains circuits to earth: 2.25 – 2.35kVdc.
Primary mains circuits to fan output (J10): 4.25 - 4.35kVDC.
Safety Approvals:
UL60950-1 and CSA22.2 No.60950-1 - UL Recognised. C-UL for Canada.
IEC / EN60950-1 - CE mark.
IEC/EN60950-1, IEC/EN 61010-1 and IEC/EN60601-1 - CB Report and Certificate.
CE marking when applied to any NV350 product, indicates compliance with the Low Voltage Directive (2006/95/EC)
in that it complies with EN60950-1, and with Directive 2011/65/EU of the European Parliament and of the Council of
8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
UL/CSA 61010-1 : UL + C–UL approval
UL/CSA 60601-1 : UL + C–UL approval
Fuse: Internal fuse (F1): 6.3A/250V fast acting HBC, 5x20mm.
Symbols:
AC EARTH
If the earth terminal of the NV350 PFC PSU is connected to the main incoming earth conductor of the end
equipment, the installer must cover the earth symbol with a label bearing the earth symbol of IEC60417-5019.
PRODUCTS COVERED
Unit Configuration Code:
NV350 PFC
ELECTRICAL & THERMAL RATINGS:
Input Parameters
Standard
Nominal input voltage (V)
Input voltage range (V)
Input frequency range (Hz)
Maximum input current (A)
Inrush Current (A)
For input voltages between 85 and 89.9V the output power is derated to 94% of the values given in the Cooling
Options Table.
Operation
Indoor
0°C - +65°C (derating above 50°C at 2.5%/°C)
5 - 95% RH, non-condensing
-200m - 5000m*
54kPa - 106kPa
Any subject to Customer Air Cooling
section
N – Neutral
60950-1
100 - 240
85 - 264
47 - 440
5.5
IIIb
2
II
I
0.3kg
IPX0
L – Live
60601-1
100 - 240
85 - 264
47 - 63
5.5
<15
Page 13 of 18
Storage
-
-40°C - +85°C
5 - 95% RH, non-condensing
-200m - 5000m
54kPa - 106kPa
All
61010-1
100 - 240
85 - 264
47 - 440
5.5
17160 issue 8, Jan 2015
