BCS Q40BBAA-PIM20C-EP _ _ _ -GS04
Capacitive Proximity Switches
7
System Functions (continued)
Behavior IO-Link
With Behavior IO-Link, the behavior of the pins during
active IO-Link communication can be determined. The pin
can either continue to perform its function or become
inactive.
Value Name
Pin 4
0x00 (0) IO-Link
Pin 2
0x00 (0) Inactive
0x01 (1) Normal Operation
Tab. 7-13: Pin assignment – Behavior IO-Link
Mode
The function of the pin can be selected with Mode.
Value Name
0x00 (0) Inactive
0x01 (1) Digital Output
0x03 (3) Digital Input
Tab. 7-14: Pin assignment – Mode
Signal Source
With Signal Source, the internal signal source for the pin
can be selected. Various signal sources are available that
can be output or read on a pin.
Value Name
Digital Output
0x0007 (7) Switching Counter Reset Channel 1
0x003E (62) Teach-In
0x0091 (145) Switching Counter Reset Channel 2
0x0092 (146) Switching Counter Reset Channel 3
0x0093 (147) Switching Counter Reset Channel 4
0x00CB (203) Switching Speed Reset Channel 1
0x00CC (204) Switching Speed Reset Channel 2
0x00CD (205) Switching Speed Reset Channel 3
0x00CE (206) Switching Speed Reset Channel 4
Digital Input
See Tab. 6-3 on page 42
Tab. 7-15: Pin assignment – Signal Source
76 english
Description
This is the communication pin. It cannot execute any other
function during an active IO-Link connection.
The pin has no function and is high-impedance.
The pin retains its function.
Description
The pin has no function and is high-impedance.
The pin works as a digital output.
The pin works as a digital input.
Description
Switching Counter Reset Channel 1
Teach-In
Switching Counter Reset Channel 2
Switching Counter Reset Channel 3
Switching Counter Reset Channel 4
Switching Speed Reset Channel 1
Switching Speed Reset Channel 2
Switching Speed Reset Channel 3
Switching Speed Reset Channel 4
