Step 5
Var.1: For display with a curved back
D
x4
Var.2: For display with a flat back
D
** If the screws "G, I, K, M" are too long, use the plastic spacers "D". (like in Step 5 Var.1)
All manuals and user guides at all-guidesbox.com
F
x4
E
x4
G I K M
, , ,
* Use the matching screws and spacers for your display.
F
x4
E
x4
H J L N
, , ,
G I K M
, , ,
* Use the matching screws and spacers for your display.
x4 *
x4 *
x4 */**
7
Display back
Display back
